LIGHT SOURCE TECHNICAL SPECIFICATIONS;

Model Name: TRON 6

Product Type: Programmable 6-Channel New Generation Fiber Optic Lighting Light Source

Light Source: PIXEL RGB-W POWER LED

Power: 24 Watts (24W POWER LED)

Number of Channels: 6 Independent Programmable Outputs (6-Channel)

Output Size: 14mm x 6 Channel Outputs

Design: 24x4x2.2 cm MINIMAL DESIGN

Body: Aluminum-Cooled Body

Input Voltage/Power: 12V DC - 5A

Warranty: 2-YEAR International Warranty

Light and Color Features

Color Palette: PIXEL RGB - COOL WHITE Power Chip (RGB + Cool White)

Effects: ANIMATED PIXEL RGB-W

Control: FLAWLESS FULL CONTROL

Connectivity and Control Features

Wireless Connections:

Wi-Fi

Bluetooth

2.4G RF (Radio Frequency)

Control Methods:

Mobile App Control (via tablets and smartphones)

Remote Control (2.4G RF)

Smart Home Integration:

Google Assistant (Works with Google Assistant)

Amazon Alexa (Works with Amazon Alexa)

Additional Functions

Programmability: Fully programmable

Sound Support: SOUND (sound synchronization/control feature)

Protection: AI-POWERED PROTECTION HARDWAREIntelligence: AI POWERED (Artificial Intelligence Supported)

🌟 TRON 6: The New Generation Fiber Optic Lighting Source That Pushes the Limits

🌌 Control the Light of Your Imagination: Flawless Full Control

TRON 6 is a Programmable 6-Channel New Generation PIXEL RGB-W POWER LED light source that takes fiber optic lighting systems to a whole new dimension. Going beyond traditional lighting, it gives you absolute control and unlimited creativity in your fiber optic star ceiling, floor, or wall designs.

🧠 AI-Powered Smart Performance

The device is reinforced with AI-Powered Protection Hardware that both optimizes the light effects and protects the system against overloads. Thanks to AI POWERED technology, you experience not just lighting but a truly smart system management experience.

🌈 Dynamic Colors in Pixel Perfection

This 24W light source features special chips that deliver PIXEL RGB and crystal-clear COOL WHITE light. Six independent programmable outputs let you control each channel with different colors and animations. With the ANIMATED PIXEL RGB feature, you can create dynamic, vivid effects such as shooting stars across your sky, flame effects, or breathtaking color transitions.

🔗 Total Freedom in Connectivity and Integration

TRON 6 takes ease of use to the top with its rich connectivity options:

Multiple Wireless Control: Control it easily from inside your home or remotely with Wi-Fi, Bluetooth, and long-range 2.4G RF technologies.

Smart Home Compatible: Works seamlessly with Google Assistant and Amazon Alexa, letting you manage your lighting with voice commands alone.

Unlimited Synchronization: Thanks to FULL SYNCHRONIZATION WITH EXTERNAL SOFTWARE, it can work in perfect harmony with your professional automation and entertainment systems.

Dance with the Music: The SOUND feature synchronizes your lighting effects with the rhythm of the music in the room, creating a one-of-a-kind ambiance.

✨ Minimalist Design, Maximum Efficiency

With its ultra MINIMAL DESIGN measuring just 24x4x2.2 cm, TRON 6 can be easily integrated into any space. Its Aluminum-Cooled Body preserves the device's performance, ensuring maximum efficiency and a long service life even under heavy use.

Whether you envision a professional cinema room, luxurious in-car lighting, or a peaceful star ceiling in your bedroom, TRON 6 is designed to bring all of these visions to life.

🎮 TRON 6 Remote Control Features (2.4G RF)

This remote control is used to operate the TRON 6 lighting controller via 2.4G RF technology.

📱 CORAX-TRON Mobile App Features and Functions

The CORAX-TRON mobile app offers users advanced lighting control in four main modes: Dynamic, Solid, Music, and DIY (Do It Yourself).

1. Basic Control and Color Selection

Color Palette:

At the center of the app is a full-spectrum Color Wheel that lets you choose from millions of color shades.

Users can fine-tune the color precisely by moving the cursor on the wheel.

Frequently used colors can be stored as Saved colors for quick access.

Option to switch to White light control (taking advantage of the RGB-W Power LED feature).

Quick Colors: Predefined Regular colors such as red, green, and blue can be selected quickly at the bottom of the screen.

2. Lighting Modes and Effects

The app comes with multiple built-in effect modes:

Dynamic Mode:

Includes moving effects such as automatic color transitions, flows, glows, and flashes.

Choose from a variety of preset dynamic effects.

Solid Mode:

Keeps the selected color lit steadily.

The desired color can be set instantly using the color wheel or the quick colors.

Music Mode:

Makes the lights react in sync with the ambient sound or the music on your phone.

Offers visual, sound-matched animations and effects such as the "Full Color VuMeter" shown in the image.

Switch between sub-modes suited to different music rhythms or styles.

DIY (Do-It-Yourself Effect Mode):

Lets users create their own customized lighting effects.

Color Array: The user can define a sequence of colors (for example, 16 different color steps).

Mode Selection: Determines how the created color sequence runs (e.g. Solid, Gradient, Flash, etc.).

This way, users can program unique and personalized animations.

3. Timing and Automation

Timers:

Set programmable timers to turn the lights on (Action: On) or off (Action: Off) at a specific time.

Choose whether the timer action runs Once or repeats (the image shows the Once setting).

The app includes a note that minor deviations in timing may occur.

4. User Interface and Additional Functions

On/Off Icon: A main control icon in the top right corner of the app turns the light on and off.

Settings/Sharing Icons: Menu icons at the top of the screen provide access to settings, device sharing, and other options.

Multi-Device Control: The app can manage more than one CORAX-TRON device (as indicated by the arrow icons visible in the top left of the image).

With this mobile app, you keep full control of your TRON 6 system, unleash your creativity, and integrate your lighting into your lifestyle.

- This product is not plug and play. Professional installation is required

- Package contents are listed below.
